Caractéristiques techniques
Basic
Interface : 8 x Audio Grade 100 / 1000 Base-T
LED : 1 x Power LED (Green)
1 x Alarm LED (Red)
8 x Por t Status LEDs (Link / Activity)
Advanced
Main Clock Accuracy : 0.1 ppm at 25 °C
EMI Absorber : Silent Angel Noise Absorber (SANA)
Noise Isolator : Main Power Circuit: 17.78 dB @ 100MHz x2
Clock Gen. Circuit: 20.79 dB @ 100MHz x2
Power Adaptor : Medical Grade Power Adaptor
Power and Case
Product Power Input : External Power 5VDC at 1A
Power Consumption : Max. 5W
Product Dimension : 154.5 mm x 85 mm x 26 mm
Package Dimension : 244 mm x 214 mm x 66 mm
Case Material : Metal in Black
Safety : CE
Weight : 1.2 kg (gross weight)
